Muir Compact THOR HR4200 Horizontal Windlass – 3/8″ Ht, 4200 lb Capacity

Description

Features:

• Durable marine-grade white gloss composite housing
• Luxury chromed marine grade bronze / 316 Stainless steel running gear
• High tensile stainless steel shaft
• Heavy duty, marine grade, dual-direction motor
• Superior, heavy-duty Italian drive train
• Chain pipe & peeler
• Independent gypsy and capstan operation
• Front double twin footings

Specifications:

• Recommended Vessel Length: 60′ – 79′ (18 – 24 m)
• Recommended Muir Circuit Breaker: 150A/100A (12/24V)
• Motor: 1700W
• Amps Workload: 90A (12V)
• Hydraulic Pressure: 12MPa
• Hydraulic Flow: 28 L/min
• Workload: 1322 lbs (600 kg)
• Max Line Speed: 17 m/min
• Compatible Chain Sizes: 3/8″ (10 mm)
• Auto Anchor Compatible: Yes
• Net Weight DC: 141 lbs (64 kg)
• Manual Operation: MORS

Included:

• (1) Circuit Breaker & Mounting Panel
• (1) Chain Pipe
• (1) Deck Switch
• (1) Deck Mounting Studs & Fasteners
• (1) Clutch Release Handle
• (1) Manual Override System (MORS)

Owner’s Manual (5.55 MB)

Deck Template
