Motogadget mo.unit BLUE Control Module – Smart Display & Vehicle Interface

Description

Motogadget Mo.unit Blue On-board Electrical System Control Unit

The mo.unit blue is an on-board electrical system control unit that enables the quick and easy installation of new vehicle electrics without any special knowledge. The digital vehicle upgrade is the Bluetooth connection to the smartphone with innovative functions such as keyless go, tour logs, vehicle management and much more.

Technical data:

• Dimensions 90 x 53 x 30mm (L/W/H)
• Waterproof, vibration-resistant – IP69
• Weight approx. 180 g
• Fastening 2 x M5 screw, length 74mm
• Operating voltage 9V – 15V
• Operating temperature -20° to +80°C

Inputs:

• Ignition lock +12V or mo.lock
• Turn signal left
• Blinker right
• Light
• Starter
• Horn
• Brake light
• Kill switch
• Side stand
• LIN bus
• AUX1
• AUX2

Outputs:

• Turn signal left
• Blinker right
• Low beam
• High beam
• Starter
• Horn
• Brake light
• Ignition
• AUX1 (Universal)
• AUX2 (Universal)

– INSTRUCTION MANUAL DOWNLOAD –
