International Dock Products SPC-36-2T-374 Slim-Line Dockside Power Pedestal

Description

International Dock’s (SPC-36-2T-374) Dockside Electrical Pillar is designed to be mounted vertically on the dock and features a slim profile that accommodates a variety of outlets and accessories.

Features:

• Compact and space saving unit that measures only 36″ tall
• Yellow thermoplastic cover
• Power cord twist locks into the pedestal at a 90 deg. angle to the receptacle (straight out from the side) and are protected by individual Square D circuit breakers
• 100% Aluminum casing, powder coated inside and out
• Fully pre-wired
• No need for additional cable ends, simply clamp your power feed wiring directly to the easy access power block
• Includes a dusk to dawn photocell controlled night light, and two single lever ball valve style hose spigots

Available Options: Contact us here to order these extra options.

• Power block – loop feed (stud) – maximum wire size 500MCM cable
• TV/telephone receptacle
• LED lighting and photocell
• Electric meters
• Water meters with locking ball valves available on larger 45″ units
• Custom heights available
• Hose holders / cable brackets
• European power receptacles
• Single and three phase 100A service available
• Natural aluminum finish and custom colors available

Note: Let us provide a quote for new pedestals for your Marina or Yacht Club. Every unit hand made in the USA to your specifications.

Specifications:

• Dimensions: 6″ x 6″ x 36″
• Construction: Aluminum
• Hardware material: Stainless steel
• Finish: Powder coated white
• Warranty:
  • 15-Year unconditional on structural integrity of 100% aluminum casing
  • 2-Year unconditional on construction and fabrication of casing and covers
  • 2-Year unconditional on HUBBELL® receptacles-unlimited on manufacturing defects
  • 1-Year on SQ D®breakers

Included:

• (2) 30A 125V Twistlock receptacles
• (2) Water faucets
• Light and photocell

Slim Line Power Pedestal Dockside Electrical Pillar Dimensional Drawing

Slim Line Power Pedestal Dockside Electrical Pillar Wiring Diagram
