Airmar’s low-profile, Chirp-ready transducers are the perfect addition to smaller boats such as center consoles. The B175L series transmits across low frequencies from 40 to 60 kHz, delivering excellent coverage and tracking. This transducer provides up to 20 kHz of total bandwidth in a single installation, offering tremendous deep-water performance for serious anglers.
Tilted Element™ technology features a ceramic element fixed at a specific angle within the housing. When the transducer is installed almost flush to the hull, the tilt of the element corrects for the hull deadrise, orienting the beam directly down. This ensures maximum echo returns to the transducer for more accurate depth readings and superior target separation.
Features:
- Depth and fast-response water-temperature sensing
- 1 kW of power for exceptional deep-water performance
- Low frequency: 40 to 60 kHz
- 32° to 21° beamwidth
- Maximum depth of 762 m (2500′)
- Low-profile, thru-hull housing provides high-quality display resolution at speed when installed properly
- Recommended for stepped, planing, or displacement hulls
- Bronze housing specifically designed for use in fiberglass or wood hulls
- Patented Xducer ID® technology
Specifications:
- Power Rating: 1 kW
- Max Deadrise Angle: Up to 24°
- Housing: Bronze
- Functions: Depth, Temperature
- Hull Material: Fiberglass or wood
- Max Vessel LOA: Up to 11 m (36′)
- Hole Size: Fiberglass or wood hull 95 mm (3-3/4″), Metal hull 105 mm (4-1/8″)
- Usable Shaft Length: 71 mm (2.80″)
- Mounting Style: Tilted Element Thru-Hull
- Acoustic Window: Urethane
- Common Use: Fishing
- Low Frequency: 40-60 kHz
- Low Frequency Beamwidth: 32°-21°
- Max Depth: 762 m (2500′)
- Retractable housing: No
- Single or Dual Frequency: CHIRP-Ready Single-Band
- Tilted Element: Yes
- Weight: 2.7 kg (6 lbs.)
